FOX Offroad Shocks
FACTORY RACE 3.5 X 18 EXTERNAL BYPASS (5 TUBE, 1") PIGGYBACK SHOCK (RIGHT)

$2,919.95

By FOX Offroad Shocks -

#FOX 98135407R

Your Vehicle
Uncompromised performance through FOX’s patented internal bypass technology delivers the feel of near-endless suspension travel. Exclusive internal bypass technology allows oil to flow around the piston at some points of the stroke – while creating humongous pressure at other points – supporting the vehicle like no other product can. Floating through terrain is accomplished with FOX’s ride zone – combining a race-developed shock piston, internal bypass and Dual Speed Compression adjustment – allowing fine tuning for weight, terrain and speed. Dominate any terrain with the brute strength of 3- and 2.5-inch aluminum bodies, cactus cooler reservoirs and 7/8” shafts with redundant seals, all proven in the harshest of environments under the toughest of conditions.

Description

FOX devotes countless hours of research and development to design race-winning suspension that withstands incredible punishment and provides consistent performance you can rely on. Regardless of whether you are flying high over the desert or struggling to stick to a rock face on an off-camber climb, our shocks will give you the damping performance, suspension control and proper spring rate to get the job done.

Specifications

Title:

FACTORY RACE 3.5 X 18 EXTERNAL BYPASS (5 TUBE, 1") PIGGYBACK SHOCK (RIGHT)

Series:

Factory Race

Body Material:

Steel

Extended Length (IN):

46.45

Type:

External Bypass

Body Diameter (in):

3.5

Top Mount:

Eyelet

Travel (in):

18.00

Reservoir Type:

Piggyback

Bottom Mount:

Eyelet

Compressed Length (in):

28.45

Fox Catalog:

OFFROAD

Label Name:

3.5 FRS, EXBP, 5T (1"), P/B, 18", RH

Adjuster Type:

External Bypass Clicker - Gen 3

Mounting:

5/8 x 1-1/2

Shaft Size (in):

1

Valving:

807-24-701

Reservoir Dimensions:

3.00 x 16.00

Body Finish:

FOX Grey Cerakote

Eyelet Length (in):

2.05

Bypass Tubes:

5

California Proposition 65:

! WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Prop 65 Y/N:

Y

Prop 65 - Long Label:

! WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Installation

FOX605-00-035_REV_B.pdf
