Rough Country
3 Inch Lift Kit

$569.95 Price Match Request Badge

By Rough Country -

#ROU 50220

Your Vehicle

Select Your Delivery Method

Does NOT F-350 models. Does NOT fit dually models. Does NOT fit 4" rear axle tubes Does NOT work on models equipped with Tremor Factory Trim Package If equipped with factory top mount overload spring it will need to be removed

Description

Give your 17-20 Ford Super Duty an impressive upgrade, front to back with Rough Country's 3" Suspension Lift Kit! This easy-to-install lift kit raises the front of your vehicle to be equal height with the rear for a leveled, better-than-stock look that gives an improved ride height and more aggressive appearance. This kit features a set of front, lifted coil springs spacers allowing you gain additional ride height without sacrificing ride quality or performance. A set of radius arm drop brackets as well as a track bar drop bracket are provided to keep everything at optimum angles for a factory-like ride, even after lifting. A set of Rough Country's premium N3 shocks are also included. These fine tuned 10-stage variable high-pressure Nitrogen charged shocks offer a fantastic blend of off-road action and smooth highway ride quality. With a durable 18mm spring-loaded piston rod and faster-cooling 54mm shock body. Get the wheels you want! Rough Country's 3" Suspension Lift Kit comes with everything you need to fit up to a 35" tire with proper wheel backspacing. Best of all, Rough Country's 3" Suspension Lift Kit is backed by our Lifetime Replacement Warranty.

Specifications

Prop 65 (C, R, or CR):

CR

Shipping Group:

No Restrictions

Utv Product:

N

Title:

Rough Country - 3 Inch Lift Kit - Ford F-250 Super Duty 4WD (2017-2022)

Category:

Susp Lift Kits 4wd

Shipping Options:

No Restrictions

Ships in Multiple Boxes:

Y

Install Time:

3-4 hours

Front Components:

Coil spring spacers, Radius arm drop brackets, Track bar drop bracket, Hardware

Rear Components:

4in lift blocks, U-bolts, Hardware

Tire, Wheel, and Offset Info:

35x12.50R20:Factory 20:8x170:-:-; 35x12.50R18:Factory 18:8x170:-:-; 35x12.50R17:Factory 17:8x170:-:-; 35x12.50R17:17x8.5:8x170:+0:Minor Trimming; 35x12.50R17:17x8.5:8x170:+1:Minor Trimming; 35x12.50R17:17x9:8x170:+0:Minor Trimming; 35x12.50R17:17x9:8x170:+1:Minor Trimming; 35x12.50R17:17x9:8x170:+18:Minor Trimming; 35x12.50R17:17x9:8x170:+20:Minor Trimming; 35x12.50R18:18x8.5:8x170:+0:Minor Trimming; 35x12.50R18:18x8.5:8x170:+1:Minor Trimming; 35x12.50R18:18x9:8x170:+0:Minor Trimming; 35x12.50R18:18x9:8x170:+1:Minor Trimming; 35x12.50R18:18x9:8x170:+18:Minor Trimming; 35x12.50R18:18x9:8x170:+20:Minor Trimming; 35x12.50R20:20x9:8x170:+0:Minor Trimming; 35x12.50R20:20x9:8x170:+1:Minor Trimming; 35x12.50R20:20x9:8x170:+18:Minor Trimming; 35x12.50R20:20x9:8x170:+20:Minor Trimming; 35x12.50R20:20x10:8x170:-25:Minor Trimming; 35x12.50R20:20x10:8x170:-24:Minor Trimming; 35x12.50R20:20x10:8x170:-19:Minor Trimming; 295 60R20:20x10:8x170:-19:-; 35x12.50R20:20x10:8x170:-18:Minor Trimming; 295 60R20:20x10:8x170:-18:-; 35x12.50R20:20x12:8x170:-44:Minor Trimming; 35x12.50R22:22x10:8x170:-25:Minor Trimming; 35x12.50R22:22x10:8x170:-24:Minor Trimming; 35x12.50R22:22x10:8x170:-19:Minor Trimming; 35x12.50R22:22x10:8x170:-18:Minor Trimming; 35x12.50R22:22x12:8x170:-44:Minor Trimming

Prop 65 (C, R or CR):

CR

Prop 65 Yes/No:

Yes

Prop 65 Warning Label:

Warning - Both Cancer and Reproduction.JPG

Prop 65 - Short Label:

WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov

Installation

ROU921502200E.pdf

Product Fitments

2017-2020 Ford F-250 Super Duty
2017-2022 Ford F-250 Super Duty King Ranch
2017-2022 Ford F-250 Super Duty Lariat
2018-2022 Ford F-250 Super Duty Limited
2017-2022 Ford F-250 Super Duty Platinum
2017-2022 Ford F-250 Super Duty XL
2017-2022 Ford F-250 Super Duty XLT
